MSI z87 mpower max ac [98/116] Software configuration

Appendix A

A-2Realtek Audio

Software Conguration

After installing the audio driver (see Chapter 1 - Driver and Utilities), the “Realtek HD

Audio Manager” icon will appear at the notication area (lower right of the screen).

You may double click the icon and the GUI will pop up accordingly.

double click the icon

It is also available to enable the audio driver by clicking the Realtek HD Audio

Manager from the Control Panel.

Software panel overview

The following gure describes the function of the Realtek HD Audio Manager panel.

Device Selection

Volume Adjustment

Application Enhancement

Jack status panel
