‑ Be careful when cutting splintery wood. Cut pieces of wood

may be pulled along (risk of injuries).

‑ When cutting with the upper edge of the guide bar, the chain

saw may be pushed in the direction of the user if the chain

gets clamped. For this reason use the lower edge of the bar

whenever possible. The chain saw will then be pushed away

from you (15).

‑ If the timber is under tension (16), rst cut the pressure side

(A). Then the crosscut can be performed on the tension side

(B). Thus clamping of the guide bar can be avoided.

CAUTION:

People felling trees or cutting of branches

must be specially trained. High risk of inju-

ries!

‑ When cutting of branches, the chain saw should be supported

on the trunk. Do not use the end of the bar for cutting (risk of

kickback).

‑ Be aware of branches under tension. Do not cut free branches

from below.

‑ Never perform detensioning cuts while standing on the

trunk.

‑ Before cutting down a tree ensure that

a) only those people are within the working area which are

actually involved in cutting down the tree.

b) every worker involved can withdraw without stumbling (the

people should withdraw backwards in a diagonal line, i.

e. at a degree of 45°).

c) the bottom part of the trunk is free from foreign objects,

underbrush and branches. Make sure to have a safe foot‑

ing (risk of stumbling).

d) the next working place is at least 2 1/2 tree lengths away

(17). Before cutting down the tree check the direction of

fall and make sure that there are neither people nor objects

within a distance of 2 1/2 tree lengths.

‑ Judging the tree:

Direction of hanging ‑ loose or dry branches ‑ height of the

tree ‑ natural overhang ‑ is the tree rotten?

‑ Take into account the direction and speed of the wind. If strong

gusts are occurring, do not do any felling.

‑ Cutting the roots:

Start with the strongest root. First do the vertical and then the

horizontal cut.

‑ Notching the trunk (18, A):

The notch determines the direction of fall and guides the tree.

The trunk is notched perpendicular to the direction of fall and

penetrates 1/3 ‑1/5 of the trunk diameter. Perform the cut near

the ground.

‑ When correcting the cut, always do so over the whole width

of the notch.

‑ Cut down the tree (19, B) above the bottom edge of the notch

(D). The cut must be exactly horizontal. The distance between

both cuts must be approx. 1/10 of the trunk diameter.

‑ The material between both cuts (C) serves as a hinge.

Never cut it through, otherwise the tree will fall without any

control. Insert felling wedges in time.

‑ Secure the cut only with wedges made of plastic or aluminium.

Do not use iron wedges. If the saw hits an iron wedge the

chain can be seriously damaged or torn.

‑ When cutting down a tree always stay sidewards of the falling

tree.

‑ When withdrawing after having performed the cut, be alert

for falling branches.

‑ When working on sloping ground the user of the chain saw

must stay above or sidewards of the trunk to be cut or the

tree already cut down.

‑ Be alert for trunks which may roll towards you.

= cutting down area
