![Makita hm1203c [4/40] Specifications](/views2/1175430/page4/bg4.png)
4
ENGLISH
Explanation of general view
1-1. Switch lever
2-1. Adjusting dial
3-1. Power-ON indicator lamp (green)
3-2. Service indicator lamp (red)
4-1. Side handle
4-2. Clamp nut
5-1. Bit shank
5-2. Bit grease
6-1. Releasing cover
8-1. Releasing cover
9-1. Change ring
12-1. Screws
13-1. Connector
13-2. White
13-3. Black
14-1. Screwdriver
14-2. Crank cap cover
15-1. Grease
16-1. Connector
16-2. White
16-3. Black
SPECIFICATIONS
Model HM1213C HM1203C
Blows per minute 950 - 1,900 min
-1
Overall length 576 mm
Net weight 10.8 kg 9.7 kg
Safety class II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE045-1
Intended use
The tool is intended for chiselling work in concrete, brick,
stone and asphalt as well as for driving and compacting
with appropriate accessories.
ENF002-1
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
For Model HM1213C
ENG102-2
For European countries only
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
) : 75 dB(A)
Sound power level (L
WA
) : 95 dB(A)
Uncertainty (K) : 2.5 dB(A)
Wear ear protection
ENG216-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745-2-6:
Work mode : chiseling function with side handle
Vibration emission (a
h,CHeq
) : 7.0 m/s
2
Uncertainty (K) : 1.5 m/s
2
For Model HM1203C
ENG102-2
For European countries only
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
) : 81 dB(A)
Sound power level (L
WA
) : 95 dB(A)
Uncertainty (K) : 2 dB(A)
Wear ear protection
ENG216-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745-2-6:
Work mode : chiseling function with side handle
Vibration emission (a
h,CHeq
) : 15.5 m/s
2
Uncertainty (K) : 1.5 m/s
2
ENH213-1
EC Declaration of Conformity
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):
Designation of Machine: Demolition Hammer
Model No./ Type: HM1213C, HM1203C
are of series production and
Conforms to the following European Directives:
2000/14/EC, 98/37/EC until 28th December 2009
and then with 2006/42/EC from 29th December
2009
And are manufactured in accordance with the following
standards or standardised documents:
EN60745
