6 7
Easy Cable Connection
With data and power over Ethernet from one unit, the ST-810HP reduces cabling
requirements and eliminates the need for dedicated electrical outlets on the
wall, ceiling or any unreachable place. A wire that carries both data and power
can lower the installation costs, simplify the installation effort and eliminate the
need for electricians or extension cords. Providing 8 PoE interfaces, the ST-810HP
is ideal for small businesses and workgroups requiring deploying the PoE for the
wireless access points, IP-based surveillance camera or IP phones in any places
easily, efciently and cost-effectively.
1.3 Features
RJ-45 Interface
8-Port 10/100Mbps Fast Ethernet Switch
8-Port supports 48V DC power to PoE Powered Device (ST-810P)
8-Port supports 56V DC power to PoE Powered Device (ST-810HP)
1-Port 10/100/1000Mbps Gigabit Ethernet Switch
Power over Ethernet
Complies with IEEE 802.3af / 802.3at Power over Ethernet End-Span PSE
Up to 8 IEEE 802.3af devices powered
Supports PoE Power up to 15.4 watts for each PoE port
Up to 3 IEEE 802.3at devices powered (ST-810HP only)
Supports PoE Power up to 30 watts for each PoE port (ST-810HP only)
120-watt PoE budget
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m
Switching
Hardware based 10/100Mbps Auto-Negotiation and Auto MDI/MDI-X (Port 1 to
Port 8)
Hardware based 10/100/1000Mbps Auto-Negotiation and Auto MDI/MDI-X
(Port 9)
Flow control for Full Duplex operation and back pressure for Half Duplex
operation
Integrates address look-up engine, supporting 4K absolute MAC addresses
Automatic address learning and address aging
Hardware
12-inch desktop size, 1U height
LED indicators for system power, per port PoE ready and PoE activity, speed,
Link / Act
1 silent fan to provide stable and efcient power performance
1.4 Specications
Model ST-810P ST-810HP
Hardware Specications
Network Connector
8-Port RJ-45 for 10/100Base-TX (Port 1 to Port 8)
1-Port RJ-45 for 10/100/1000Base-T (Port 9)
PoE Inject Port
8-Port with 802.3af PoE
injector function
8-Port with 802.3at PoE
injector function
LED Display
System: Power (Green)
Per PoE port: PoE (Orange)
LNK/ACT (Green)
Gigabit port: Speed (Green)
LNK/ACT (Green)
Switch Architecture Store and Forward switch architecture
MAC Address Table 4K MAC address table with auto learning function
Switch Fabric 3.6Gbps
Switch Throughput 2.67Mpps@64Bytes
Flow Control
Back pressure for Half-Duplex. IEEE 802.3x Pause
Frame for Full-Duplex
