SC743 Chassis Manual
3-2
3-3 Where to get Replacement Components
Although not frequently, you may need replacement parts for your system. To
ensure the highest level of professional service and technical support, we strongly
recommend purchasing exclusively from our Supermicro Authorized Distributors/
System Integrators/Resellers. A list of Supermicro Authorized Distributors/System
Integrators/Resellers can be found at: http://www.supermicro.com. Click the Where
to Buy link
3-4 Front Control Panel
The following diagram denes each component of the front LED panel.
1
2
3 4 5
6
10
987
Power Button1.
System Reset2.
Power Indicator3.
HDD Activity Indicator4.
LAN1 Indicator5.
LAN2 Indicator6.
CPU Temperature/Fan Failure Indicator7.
Power Failure Indicator8.
USB Port9.
USB Port10.
Figure 3-1: Front Control Panel
