Supermicro CSE-743TQ-865 [60/104] Jumper settings and locations for the cse m35t sata

SC743 Chassis Manual

C-6

Jumper Settings and Locations for the CSE-M35T (SATA)

JP18

JP25

Channel #2

Channel #3

Channel #4

Channel #1

JP28

ACT2

ACT3

ACT4

COM

K e y

JP26

ACT1

Activity LEDs Pin Denitions JP26

Act. LED1 = Channel 1

Act. LED2 = Channel 2

Act. LED3 = Channel 3

Act. LED4 = Channel 4

Figure C-2: Jumper Locations
