Chapter 4: AMI BIOS
4-39
Authorized Signatures
Delete DB (DataBase)
Select <Yes> to conrm deletion of a database from the your system.
Set New DB (DataBase)
Select <Yes> to conrm that a new DB from the factory defaults will be set in the
system.
Append DB (DataBase)
Select <Yes> to load the new database from the manufacture defaults to your
system. Select <No> to load the new database from other sources.
Authorized TimeStamps
Delete DBT (DataBase Timer)
Select <Yes> to conrm deletion of the database timer from the system.
Set New DBT (DataBase Timer)
Select <Yes> to conrm that the new database timer from factory defaults will be
set in the system.
Append DBT (DataBase Timer)
Select <Yes> to load the new database timer from the manufacture defaults. Select
<No> to load the new database timer from other sources
Forbidden Signatures
Delete DBX
Select <Yes> to conrm deletion of the DBX les from the system.
Set New DBX
Select <Yes> to conrm that the new DBX les from the factory defaults will be
set for the system.
Append DBX (DataBase Timer)
Select <Yes> to load the new DBX les from the manufacture defaults to the system.
Select <No> to load the new DBX les from other sources.
