Chapter 4: AMI BIOS
4-25
Onboard LAN1 Option ROM/Onboard LAN2 Option ROM/Onboard Video
Option ROM
Use this option to select the type of device installed in LAN Port1, LAN Port2
or the onboard video device used for system boot. The default setting for LAN1
Option ROM is PXE, for LAN2 Option ROM is Disabled, and for Onboard Video
Option ROM is Legacy.
VGA Priority
Use this item to select the graphics device to be used as the primary video display
for system boot. The options are Onboard and Offboard.
Network Stack
Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Uni-
ed Extensible Firmware Interface) for network stack support. The options are
Enabled and Disabled.
IPv4 PXE Support (Available when Network Stack is set to Enabled)
Set this item to Enabled to activate IPv4 PXE Support. The options are Enabled
and Disabled.
IPv6 PXE Support (Available when Network Stack is set to Enabled)
Set this item to Enabled to activate IPv6 PXE Support. The options are Enabled
and Disabled.
Super IO Conguration
Super IO Chip AST2400
Serial Port 1 Conguration/Serial Port 2 Conguration
Serial Port 1/Serial Port 2
Select Enabled to enable the onboard serial port specied by the user. The options
are Enabled and Disabled.
Device Settings
This item displays the base I/O port address and the Interrupt Request address of
a serial port specied by the user.
Change Port 1 Settings/Change Port 2 Settings
This feature species the base I/O port address and the Interrupt Request address
of Serial Port 1 or Serial Port 2. Select Auto for the BIOS to automatically assign
the base I/O and IRQ address to a serial port specied.
