X2 APIC (Advanced Programmable Interrupt Controller)
Based on Intel's Hyper-Threading architecture, each logical processor (thread) is
assigned 256 APIC IDs (APIDs) in 8-bit bandwidth. When this feature is set to En-
able, the APIC ID will be expanded (X2) from 8 bits to 16 bits to provide 512 APIDs
to each thread to enhance CPU performance. The options are Disable and Enable.
AES-NI
Select Enable to use the Intel Advanced Encryption Standard (AES) New Instruc-
tions (NI) to ensure data security. The options are Enable and Disable.
Intel Virtualization Technology
Select Enable to use Intel Virtualization Technology support for Direct I/O VT-d sup-
port by reporting the I/O device assignments to the VMM (Virtual Machine Monitor)
through the DMAR ACPI tables. This feature offers fully-protected I/O resource
sharing across Intel platforms, providing greater reliability, security and availability
in networking and data-sharing. The options are Enable and Disable
Advanced Power Management Conguration
Advanced Power Management Conguration
Power Technology
Select Energy Efcient to support power-saving mode. Select Custom to customize
system power settings. Select Max Performance to optimize system performance.
Select Disabled to disable power-saving settings. The options are Disable, Energy
Efcient, and Custom.
*If the option is set to Custom or Energy Efcient, the following items will display:
Energy Performance Tuning (Available when Power Technology is set to
Custom or Energy Efcient)
Select Enable for energy-performance tuning support to enhance energy ef-
ciency, which might compromise system performance. The options are Enable
and Disable.
Energy Performance Bias Setting (Available when Power Technology is
set to Custom or Energy Efcient)
Use this feature to select an appropriate fan setting to achieve maximum system
performance (with maximum cooling) or maximum energy efciency with maxi-
mum power saving). The fan speeds are controlled by the rmware management
via IPMI 2.0. The options are Performance, Balanced Performance, Balanced
Power, and Power.
