Chapter 4: AMI BIOS
4-23
Server ME (Management Engine) Conguration
This feature displays the following system ME conguration settings.
• General ME Conguration
• Operational Firmware Version
• Recovery Firmware Version
• ME Firmware Features
• ME Firmware Status #1
• ME Firmware Status #2
• Current State
• Error Code
PCIe/PCI/PnP Conguration
The following PCI information will be displayed:
PCI Bus Driver Version
PCI Devices Common Settings:
PCI Latency Timer
Use this item to congure the PCI latency timer for a device installed on a PCI bus.
Select 32 to set the PCI latency timer to 32 PCI clock cycles. The options are 32,
64, 96, 128, 160, 192, 224 and 248 (PCI Bus Clocks).
PCI-X Latency Timer
Use this item to congure the PCI-X latency timer for a device installed on a PCI -X
bus. Select 32 to set the PCI-X latency timer to 32 PCI-X clock cycles. The options
are 32, 64, 96, 128, 160, 192, 224 and 248 (PCI Bus Clocks).
PCI PERR/SERR Support
Select Enabled to allow a PCI device to generate a PERR (PCI/PCI-E Parity Error)
or an SERR (System Error) number for a PCI bus error event. The options are
Enabled and Disabled.
Above 4G Decoding (Available if the system supports 64-bit PCI decoding)
Select Enabled to decode a PCI device that supports 64-bit in the space above 4G
Address. The options are Enabled and Disabled.
