57
Delay
English
Sync
Activate Sync if you want to adopt the host application’s tempo. Sync is
available only when BPM is activated.
The stand-alone version does not interface with host applications, so you won’t find
this button in this version. Tempo is determined by the value indicated manually under
Tempo.
Tempo
Tempo appears only when BPM mode is enabled. The program requires a
reference tempo to compute delay times on the basis of note values. Enter
the reference tempo here manually. If you chose Sync, the program adopts
the host application’s tempo, and this tempo can no longer be changed in
the text box.
Divergence
Divergence blends the L, C, R, Ls and Rs signals. When this knob is set to 0,
every delay receives its assigned input signal. As you turn the knob up,
each delay receives an increasingly larger proportion of the signals origi-
nally assigned to other delays. When Divergence is maxed out, all delays get
the same signal. This feature comes in quite handy: Even when processing
monaural signals, which are limited to one channel within the panorama,
all delays can be provided with the signal.
High Damp
The delays’ feedback loop sports a low-pass filter that lets you simulate the
high-frequency loss incurred with repeated echoes. Set High Damp to a
threshold frequency; frequencies above it are dampened in the feedback
loop. The value applies equally to all delays.
wizooverbW5 en und de.book Page 57 Monday, May 30, 2005 10:59 PM
