V2403 Series Linux Software Managing Communications

3-2

Detecting Network Interfaces

Debian Linux systems use udevd to detect new network interfaces, including Ethernet interfaces and wireless

interfaces. One of the rules is /lib/udev/rules.d/75-persistent-net-generator.rules for creating a

persistent network interface naming order. The content in /etc/udev/rules.d/70-persistent-net.rules is

similar to the following:

# PCI device 0x10ec:0x8168 (r8169)

SUBSYSTEM==“net”, ACTION==“add”, DRIVERS==“?*”, ATTR{address}==“00:90:e8:00:00:20”,

ATTR{dev_id}==“0x0”, ATTR{type}==“1”, KERNEL==“eth*”, NAME=“eth0”

# PCI device 0x10ec:0x8168 (r8169)

SUBSYSTEM==“net”, ACTION==“add”, DRIVERS==“?*”, ATTR{address}==“00:90:e8:00:00:21”,

ATTR{dev_id}==“0x0”, ATTR{type}==“1”, KERNEL==“eth*”, NAME=“eth1”

The above example indicates that the system has detected two Ethernet interfaces.

ATTENTION

When replacing or connecting a network interface,

the system may keep the old record in

/etc/udev/rules.d/70

-persistent-net.rules, which could cause network interfaces to be detected

abnormally

. To avoid this problem, delete the content of the file /etc/udev/rules.d/70-persistent-net.rules

and

reboot the system.

Changing the Network Settings

The V2403 computer has two 10/100 or 10/100/1000 Ethernet ports named LAN1 and LAN2. The default IP

addresses and netmasks of these network interfaces are:

Default IP Address Netmask

LAN1 192.168.3.127 255.255.255.0

LAN2 192.168.4.127 255.255.255.0

These network settings can be modified by changing the interfaces configuration file, or they can be adjusted

temporarily with the ifconfig command.

Changing the “interfaces” Configuration File

1. Type cd /etc/network to change directories.

moxa@MOXA:~# cd /etc/network

2. Type vi interfaces to edit the network configuration file with vi editor. You can configure the V2403’s

Ethernet ports for static or dynamic (DHCP) IP addresses.

moxa@MOXA:/etc/network# vi interfaces
