V2403 Series Linux Software Managing Communications

3-16

Ethernet Bridging for Private Networks on Different Subnets

1. Set up four machines, as shown in the following diagram.

Host A represents the machine that belongs to OpenVPN A, and Host B represents the machine that belongs

to OpenVPN B. The two remote subnets are configured for a different range of IP addresses. When this

configuration is moved to a public network, the external interfaces of the OpenVPN machines should be

configured for static IPs, or connected to another device (such as a firewall or DSL box) first.

2. Generate a preset shared key by typing the following command:

# openvpn --genkey --secret secrouter.key

3. Copy the file that is generated to the OpenVPN machine:

# scp /etc/openvpn/secrouter.key 192.168.8.174:/etc/openvpn

ATTENTION

preshared key is located at /etc/openvpn/secrouter.key. You can use it for testing purposes

. We suggest

creat

ing a new key for non-testing purposes.

4. On machine OpenVPN A, modify the remote address in configuration file /etc/openvpn/tap0-br.conf.

# point to the peer

remote 192.168.8.174

dev tap0

port 1194

secret /etc/openvpn/secrouter.key

cipher DES-EDE3-CBC

auth MD5

tun-mtu 1500

tun-mtu-extra 64

ping 40

up /etc/openvpn/tap0-br.sh

#comp-lzo

5. Next, modify the routing table in /etc/openvpn/tap0-br.sh script.

#--------------------------Start---------------------------

#!/bin/sh

# value after “-net” is the subnet behind the remote peer

route add -net 192.168.4.0 netmask 255.255.255.0 dev br0

#----------------------------end---------------------------
