V2403 Series Linux Software Managing Communications

3-14

2. Establish a mount point on the NFS Client site:

#mkdir –p /home/nfs/public

3. Mount the remote directory to a local directory:

# mount -t nfs -o nolock 192.168.3.100:/home/public /home/nfs/public

(This is where 192.168.3.100 is the example IP address of the NFS server.)

SNMP

The V2403-LX comes with the SNMP (Simple Network Management Protocol) agent software pre-installed. It

supports RFC 1213 MIB-II.

By default, snmpd listens for connections from the local system. To prevent listening, remove the configuration

text agentAddress udp:127.0.0.1:161 from the system file: /etc/snmp/snmpd.conf.

Example:

root@Moxa:~# vi /etc/snmp/snmpd.conf

###############################################################################

# EXAMPLE.conf:

# An example configuration file for configuring the Net-SNMP agent ('snmpd')

# See the 'snmpd.conf(5)' man page for details

# Some entries are deliberately commented out, and will need to be explicitly activated

###############################################################################

# AGENT BEHAVIOUR

# Listen for connections from the local system only

# agentAddress udp:127.0.0.1:161

# Listen for connections on all interfaces (both IPv4 *and* Ipv6)

agentAddress udp:161,udp6:[::1]:161

……

After editing the config file, restart the snmpd daemon.

root@Moxa:~# /etc/init.d/snmpd restart

The following example shows an SNMP agent responding to a query from the SNMP browser on the host site:

root@Moxa:~# snmpwalk -v 1 -c public 192.168.3.127

iso.3.6.1.2.1.1.1.0 = STRING: "Linux Moxa 3.16.0-0.bpo.4-amd64 #1 SMP Debian

3.16.7-ckt4-3~bpo70+1 (2015-02-12) x86_64"

iso.3.6.1.2.1.1.2.0 = OID: iso.3.6.1.4.1.8691.12.2400

iso.3.6.1.2.1.1.3.0 = Timeticks: (400) 0:00:04.00

iso.3.6.1.2.1.1.4.0 = STRING: "Moxa Inc., Embedded Computing Business.

<www.moxa.com>"

iso.3.6.1.2.1.1.5.0 = STRING: "Moxa"

iso.3.6.1.2.1.1.6.0 = STRING: "Fl.4, No.135, Lane 235, Baoquao Rd., Xindian Dist.,

New Taipei City, Taiwan, R.O.C.\""

iso.3.6.1.2.1.1.7.0 = INTEGER: 72

iso.3.6.1.2.1.1.8.0 = Timeticks: (1) 0:00:00.01

iso.3.6.1.2.1.1.9.1.2.1 = OID: iso.3.6.1.6.3.10.3.1.1

iso.3.6.1.2.1.1.9.1.2.2 = OID: iso.3.6.1.6.3.11.3.1.1
