V2403 Series Linux Software Managing Communications
3-23
APN, Username, Password, PIN will be written in config file: /etc/qmi-network.conf when use "cell_mgmt start".
Next time you can use "cell_mgmt start" without OPTIONs if OPTIONs are the same as last time set.
cell_mgmt stop
Stop network.
moxa@Moxa:/home/moxa# cell_mgmt stop
Loading profile...
APN: internet
Loading previous state...
Previous CID: 8
Previous PDH: 1205656072
Stopping network with 'qmicli -d /dev/cdc-wdm1 --wds-stop-network=1205656072
--client-cid=8'...
Network stopped successfully
Clearing state...
cell_mgmt restart
Restart network.
moxa@Moxa:/home/moxa# cell_mgmt restart
Loading profile...
APN: internet
Loading previous state...
Previous CID: 8
Previous PDH: 1205716376
Stopping network with 'qmicli -d /dev/cdc-wdm1 --wds-stop-network=1205716376
--client-cid=8'...
Network stopped successfully
Clearing state...
Loading profile...
APN: internet
Starting network with 'qmicli -d /dev/cdc-wdm1 --wds-start-network=internet
--client-no-release-cid --device-open-net=net-802-3|net-no-qos-header'...
Saving state... (CID: 8)
Saving state... (PDH: 1205652720)
Network started successfully
There is no PIN code
Cellular module
cell_mgmt reset
Reset cellular module.
moxa@Moxa:/home/moxa# cell_mgmt restart
Loading profile...
APN: internet
Loading previous state...
Previous CID: 8
Previous PDH: 1205716376
Stopping network with 'qmicli -d /dev/cdc-wdm1 --wds-stop-network=1205716376
--client-cid=8'...
Network stopped successfully
Clearing state...
Loading profile...
APN: internet
