DA-681 Series Embedded Computer BIOS Setup

3-18

Method 2: Use the BootFlashDOS utility.

Run the BootFlashDOS utility and then press Start.

ATTENTION

The BootFlashDOS utility can be the following website:

http://gocoding.com/page.php?al=bootflashdos.

Step 2: Prepare the Upgrade Tool and BIOS Binary File.

You must use the BIOS upgrade installation file to upgrade the BIOS. You can download it from the Moxa

Download Center at:

http://web4.moxa.com/support/download_center.asp

1. Get the BIOS upgrade installation file. The file name should have following format:

BIOS_DA-68X_V1.0_Build_08042310.zip.

2. Copy the file to the Bootable USB Disk.

3. Double click to extract the BIOS update installation file. The file includes a binary file in the form

xxxxxxx.Sxx and the upgrade utility named awdflash.exe.

Step 3: Set up the BIOS to Boot from the USB Disk.

1. Insert the USB disk.

2. Power on and press DEL to enter the BIOS Setup menu.

3. Select Advanced  Hard Disk Boot Priority and then press Enter.

4. From the Setup menu, use “↑” or “↓” to select the USB device.

5. Press “+” to move it up to the first priority, and press “Esc” to exit the setup menu.

6. Make sure the first boot device is Hard Disk. If it isn’t, press Enter to change it.

7. Select Exit  Save & Exit Setup and then press Enter.

8. Choose Y to save to the CMOS and then exit.
