UC-8410A Series Linux Software Getting Started
2-4
5. Select E to configure the port settings according to the Serial Console Port Settings table provided
above.
6. Select Save setup as dfl (from the main configuration menu) to use default values.
7. Select Exit from minicom (from the configuration menu) to leave the configuration menu.
8. Execute minicom after completing the above configurations.
user@PC1:~# minicom
Windows Users
WARNING
DO NOT apply these steps to the UC
-8410A-LX. These steps apply to the Windows PC that you use
to connect
to the UC
-8410A-LX.
Take the following steps to connect to the UC-8410A-LX from your Windows PC:
1. Download PuTTY (http://www.chiark.greenend.org.uk/~sgtatham/putty/download.html
), the free SSH
and telnet client for Windows.
2. Run the PuTTY application (putty.exe) on the Windows PC.
3. Enter the details of the serial connection in the configuration window.
The figure below shows an example of the configuration that is required:
