UC-8410A Series Linux Software Advanced Configuration of Peripherals

3-8

Creating a System Image in a Linux Environment

If you are using Linux, take the following steps.

1. Make sure the SD card’s write protection switch is unlocked.

2. Insert the SD card into a Linux PC.

3. Use the dmesg command to determine the device node.

4. Use the dd command to configure the UC-8410A-LX image on the SD card.

root@Moxa:/home/work# sudo dd if=./140

42420.img of=/dev/sdd

bs=512k

1954+0 records in

1954+0 records out

1024458752 bytes (1.0 GB) copied, 119.572 s, 8.6 MB/s

NOTE

Click the following links for more information on the

dd command.

http://www.gnu.org/software/coreutils/manual/html_node/dd

-invocation.html

Booting up the UC-8410A-LX for the First Time

We suggest using the serial console to log in for the first time. See the UC-8410A Hardware User’s Manual for

instructions on how to connect to the serial console.

File System Resizing

Connect the UC-8410A-LX to a 12-48 VDC power source; the computer will immediately boot up. The power

LED will be light up first, after which the SD Card LED will light up. You will also see messages printed out from

the serial console. On the first boot up, you will notice that the root filesystem is being resized and initialized,

as indicated by the notification shown below.
