EM-2260 HW User’s Manual Introduction
Package Checklist
The EM-2260 Development Kit contains the following items:
y EM-2260 Embedded Module
y EM-2260-DK, the carrier board of the EM-2260 Development Kit
y Peripheral Extension Board
y Quick Installation Guide
y Document & Software CD
y Ethernet Cable: RJ45 to RJ45 cross-over cable, 100 cm
y Universal Power Adapter
y Product Warranty Paper
ATTENTION
Notify your sales representative if any of the above items are missing or damaged.
Features
The EM-2260 Embedded Module/EM-2260 Development Kit has the following features:
y Cirrus Logic EP9315 ARM9 CPU, 200 MHz
y 128 MB RAM on-board, 32 MB Flash Disk
y Graphical interface for external VGA output connection
y 4 high speed TTL serial ports
y Dual 10/100 Mbps Ethernet for network redundancy
y 8+8 DI/DO
y Support EIDE interface and USB 2.0 Host
y Ready-to-Run WinCE 6.0 or Linux platform
y Full-function development kit for quick evaluation and application development
1-4
