MC-5150-AC/DC Introduction

1-2

Overview

The MC-5150-AC/DC series computer is based on the Intel Core™ i5 520E processor and comes with 4 serial

ports, 2 Gigabit Ethernet ports, 6 USB hosts, 8 NMEA ports, and offers high performance and versatile

peripherals for marine applications.

Users can easily install Windows 7, Windows XP SP3, and Windows XP Embedded to provide a flexible and

friendly environment for system development and application implementation.

Package Checklist

The MC-5150-AC/DC Series includes the following model:

MC-5150-AC/DC:

x86 ready-to-run computers with Intel Core™ i5 520E, 4 serial ports, 2 Gigabit Ethernet ports, 6 USB hosts, 8

NMEA ports, storage, VGA/DVI

Each model is shipped with the following items:

• MC-5150-AC/DC embedded computer

• 2 removable storage protection keys

• 8 screws for internal and removable HDD

• Terminal block for power input (DC model only)

• 8 terminal blocks for NMEA ports

• Documentation and software CD

• Quick installation guide (printed)

• Warranty card

NOTE

Please notify your sales representative if any of the above items are missing or damaged.

Product Features

The MC-5150-AC/DC embedded computer has the following features:

• High performance Intel Core™ i5 520E processor, 3 MB L2 cache

• Built-in 2 GB DDR3 memory, supports up to 4 GB

• Dual independent displays (DVI-I + VGA)

• 2 Gigabit Ethernet ports for network redundancy

• 2 RS-232/422/485 serial ports

• 2 RS-232 ports

• 8 NMEA ports

• 6 USB 2.0 hosts

• 1 internal SATA storage slot for SSD

• 1 removable drive tray for SSDs or disk drives

• 1G anti-vibration design for system reliability

• Fanless design with compact size

• 24 VDC or 100 to 240 VAC power input models available

• Supports Windows XP Embedded, Windows XP SP3, Windows 7
