TRC-190 TRC-190 Rackmounting
4-3
Grounding
Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the
ground connection from the ground screw to the grounding surface prior to connecting devices. Attach the
grounding wire (12 AWG copper wire gauge or larger) to the chassis grounding lug carefully.
