Welcome
Thank you
for choosing a Loewe product. We are happy to welcome you as our customer.
At Loewe we combine the highest standards of technology, design and user
friendliness. This is equally true of TV, DVD, video, audio and accessories. Neither
technology nor design is an end in itself, but both are intended to provide our
customers with the best possible audio and visual experience. Our design is not
influenced by short-term, fashionable trends. You have, after all, purchased a
high-quality piece of equipment which you do not want to get tire of tomorrow
or the day after.
The Loewe Individual Sound Projector is the simplest way to enjoy digital surround
sound without laboriously having to arrange and connect up numerous loudspeakers
distributed around the room. We use state-of-the-art digital technology to control
several small loudspeakers in such a way that directed soundwaves and targeted
reflection off the walls of your room create the real impression of acoustic spatial
perception regardless where you are sitting - as if you were in the thick of it. And
setting up and operating the Sound Projector is quite simple.
Scope of delivery
Loewe Individual Sound Projector
Remote control Assist with 2 batteries
Mains cable
Digital audio cinch cable
Audio cinch cable
Video cinch cable and SCART adapter
Optical audio cable
System cable RS-232C
Microphone with stand
Wall mount, cover
Cable holder, adhesive holders (4x)
this user guide and mounting instructions
You can control three units using the remote control, apart from this Sound Projector,
a Loewe TV set and a Loewe recorder as well.
Trademark rights
Manufactured under licence from Dolby Laboratories. Dolby, ProLogic and the
double-D symbol
DIGITAL
are trademarks of Dolby Laboratories.
and are trademarks of Digital Theater Systems, Inc.
Manufactured under licence from 1 Ltd. Trademark protection worldwide.
The Logo and "Digital Sound Projector™" are trademarks of 1 Ltd.
TruBass, SRS and the symbol are registered trademarks of SRS Labs, Inc.
TruBass technology is manufactured under licence from SRS Labs, Inc..
This product was made with the support of YAMAHA CORPORATION.
•
•
•
•
•
•
•
•
•
•
•
•
Accessories
Table Stand I Sound Projector Order No. 67208
Floor Stand 5 MU Order No. 67471 B10
Environmental Protection
Power consumption
Your unit has been equipped with an economical standby power supply. In standby,
power consumption falls to a low level (page 27). If you want to save even more
electricity, disconnect the unit from the mains.
Cardboard Box and Packaging
In line with national regulations regarding the disposal of packaging materials, we
pay a fee to authorised recyclers who collect packaging from dealers. Nevertheless,
we recommend that you keep the original cardboard box and the rest of the
packaging materials so that the unit can, if necessary, be transported in the safest
possible conditions.
The unit
Important: The EU Directive 2002/96 /EC governs the proper
re-acceptance, handling and recycling of used electronic
appliances. Old electronic appliances must therefore be disposed
of separately. Never dispose of this unit in the normal domestic
waste! You can hand in your old unit free of charge at identified
collection points or to your dealer if you buy a similar new unit.
Other details about re-acceptance (also for non-EU countries) are
available from your local authorities.
Remote control batteries
The batteries provided contain no harmful materials such as
cadmium, lead or mercury.
Regulations concerning used batteries mean that batteries may
no longer be thrown out with the household rubbish. You can
dispose of used batteries free of charge at the collection points
in commercial outlets. Your dealer will also have a collection point
for used batteries.
