11
Fold out picture pages.
Set-up
Figure
a)Insert the flexible hose adapter into the air intake
opening and allow it to engage.
b)To remove the flexible hose, press the two lugs
together and pull the hose out.
Figure
a)Connect the handle and the telescopic tube
together.
b)Push the handle into the telescopic tube until it
engages.
To release the connection, squeeze the locking
collar and pull the handle out.
Figure
Attach the carpet lifter to the nozzle.
Press the carpet lifter sideways to engage.
Figure
a)Align and connect the floor tool and the telescopic
tube.
b)Push the telescopic tube straight into the connect-
ing piece of the floor tool until it engages.
Press on the locking collar and pull out the telescop-
ic tube to disconnect.
Figure
To release and adjust the length of the telescopic
tube, press the adjusting sleeve in the direction of
the arrow and adjust the tube to the required length.
Figure
Holding the power cord by the plug, pull out the
required length and plug it into the mains socket.
Figure
To switch your vacuum cleaner on and off, press the
ON/OFF button in the direction of the arrow.
The blue indicator in the filter status area lights up,
indicating that the appliance is ready to use.
7
6
5*
4*
3*
2*
1
en
Vacuuming
You have bought an extremely powerful appliance.
The highest suction setting is therefore only recom-
mended for heavily soiled, short-pile carpets and hard
floors.
Figure
Adjusting the floor tool:
a)For vacuuming rugs
and carpets =>
b)For vacuuming hard floors =>
Floor nozzle with carpet lifter*
Figure
When you pull the floor tool backwards, the rug is
lifted, allowing you to clean underneath its edge.
Vacuuming with accessories
Figure
Pull the combination tool in the direction of the arrow
to remove it from the tool holder.
a)Crevice nozzle
For vacuuming in crevices and corners.
For difficult to reach places, the 4 in 1 tool can be
extended to two different lengths by pulling out the
crevice nozzle.
For either length extension, pull the crevice nozzle
out until you hear it engage.
The crevice nozzle can be pushed back in again by
releasing the telescopic locking mechanism
(pressing it in the direction of the arrow).
b)Upholstery nozzle
For cleaning upholstered furniture, curtains, etc.
c)Hard furnishings brush
For window frames, cabinets, profiles, etc.
Fold the upholstery nozzle over in the direction of
the arrow.
To extend the brush ring, turn in the direction of
the arrow.
Before replacing the combination tool in the tool
holder, retract the brush ring and fold the upholstery
nozzle back.
10
9*
8
*
Dependent on model
