10
Caution!
Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.
Figure
Remove the upholstery nozzle and crevice nozzle
from the accessories holder as illustrated.
Figure
Vacuuming with accessories
Attach the nozzles to the suction pipe or handle as
required:
a)Crevice nozzle for vacuuming crevices and corners,
etc.
b)Upholstery nozzle for vacuuming upholstered
furniture, curtains, etc.
Figure
After use, push the crevice nozzle and upholstery
nozzle back into the accessories holder as indicated.
Figure
䡲 Secure the drill dust nozzle to the handle and then
place against the wall, so that the nozzle drill hole
opening sits directly over where the hole will be
drilled.
䡲 Select the lowest power setting and then switch on
the vacuum cleaner.
䡲 Suction holds the drill dust nozzle in the required
position.
Depending on the surface of the wall to be drilled,
it may be necessary to readjust the power to a high-
er setting to ensure the drill dust nozzle is firmly
attached.
Any fine particles are automatically vacuumed up.
!
Caution: the drill dust nozzle should only be used
in conjunction with the dust container since fine
drill dust can impair the function of the dust bag.
Turbo brush
If your vacuum cleaner is equipped with a turbo brush,
please consult the accompanying instruction manual
for notes on use and maintenance.
Figure
Pet hair tool
Floor tool for easy, thorough removal of pet hair
To clean the nozzle, simply vacuum it using the fixed
/ telescopic tube
Hard-floor brush
Figure
For vacuuming hard floor coverings (tiles, parquet
flooring, etc.)
16*
15*
14*
13
12*
11
Cleaning the hard-floor brush
Figure
a)Vacuum from below to clean the brushes.
b)Cut through threads and hairs wound round the
rollers using scissors.
Vacuum threads and hairs with the crevice nozzle.
Figure
You can use the parking aid on the side of the
vacuum cleaner if you wish to stop vacuuming for a
short time.
Once you have switched off the vacuum cleaner,
slide the catch on the floor tool into the groove on
the side of the appliance.
Figure
The appliance can also be carried using one of the
two handles when vacuuming steps, for example.
When the work is done
Figure
Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The cable then
rewinds automatically.
Figure
To store or transport the vacuum cleaner, use the
storage aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the
catch on the floor tool into the groove on the under-
side of the appliance.
You have purchased a floor vacuum cleaner which can
vacuum up any type of dry dirt using the dust contain-
er or dust bag.
We recommend that you use:
– the dust container, particularly for DIY-related clean-
ing, e.g. to vacuum up wood shavings, etc.
– the dust bag principally for everyday household
cleaning.
Using the dust container
!
Caution: The dust bag change indicator only works in
conjunction with a dust bag.
Figure
Set the power setting to maximum for the best results
when vacuuming.
We recommend that you reduce the setting only when
vacuuming very delicate materials.
Emptying the dust filter
To achieve an optimal result when vacuuming, the dust
container should be emptied each time the vacuum cleaner
is used.
22
21
20
19
18
17*
