- 30
Adjusting the programme list
➠ The selection is at the top of the specifications,
if not, press the blue button.
Select Date, Time, Stations or Topics.
Select defaults within the respective line.
Example If you are searching for the next news, select today’s date,
17:00 for example for the time, all for station and News
for topics. Then you get a list of all news programmes
from 17.00 h onwards in the programme list below it.
The type of list of programmes in the programme list
depends on the setting of the sorting in the EPG menu
(page
31
).
Time entry If the line Time is selected, then you can enter the time
after which the programmes will be displayed, via the
numeric buttons of the remote control. The broadcasts
are sorted according to the order of the station list within
the selected time window.
Stations If a favourites list has been selected, only the programmes
of stations from the favourites list are displayed in the
programme list. A single station can be selected with
“...”. The Select single station window is opened. After
selection, only programmes of the selected single station
are displayed.
Hint Before pressing the blue button to leave the upper selec-
tion lines, select one of the preceding lines. If you then
switch back to the programme list, you can change this
menu line with , without having to leave the pro-
gramme list. If you have marked Time, then you can enter
the time, after which the programmes will be displayed,
with the numeric buttons of the remote control.
Paging through the programme list
P+/P– Page backwards / forwards.
In the entries for Date and Time, you will see changes in
time as well as in date when paging. Scrolling in the
programme list is also possible when the selection is at
the top of the specifications.
Electronic Programme Guide – EPG
EPG stands for Electronic Programme Guide and provides you with
on-screen programme details. With the system, as with a printed pro-
gramme guide, you can learn about the current programme. In addition
programmes can be sorted according to certain topics, memorised, and
also recordings can be programmed.
Starting and ending EPG
Switch EPG on / off.
➠ A wizard will guide you through the necessary presettings
the first time you start the EPG. If you have analogue
reception, you enter the data capture for analogue
stations after that (see page 31).
➠ For TV sets with MHEG-5 software, EPG is only possi-
ble for DVB-T stations.
The display of the programme guide is divided into two
branches. The programme list (bottom) is influenced by
certain specifications (top).
Blue button: Switches between the upper default lines
Date, ..., Topics and the lower programme list.
Switching and memorizing with the programme list
➠ In the programme list first all currently running
programmes are listed.
➠ You are in the lower programme list,
if not, press the blue button.
Select station.
OK View / Memorise.
View The programme is in progress. The TV set switches to the
marked programme.
Memorise The programme has not started yet and is memorised. A
appears in front of the programme. The TV set switches over
automatically to the beginning of the programme or, if set
in the EPG menu (page 31) on from standby mode.
Electronic Programme Guide
END
MENU
P+
P–
TEXT
OK
09
-
OK
arte 15:57-16:59 Charmed - Zauberhafte Hexen
Das Erste 16:00-16:10 Tagesschau
ZDF 16:00-16:10 heute - in Europa
WDR Köln 16:00-16:15 WDR aktuell
Bayerisches... 16:00-16:05 Rundschau
hr-fernsehen 16:00-16:30 Schlemmerreise Spanien
MDR FERNS... 16:00-16:15 Hier ab vier
NDR FS HH 16:00-16:30 Tipps und Trends - Der Verbraucher...
SWR Fernse... 16:00-16:05 Baden-Württemberg aktuell
2 ZDF
EPG (Electronic Programme Guide) Mon 31.07./16:05
Detail View Record
Page ↑↓ Select time Select date, ... , topics
Date
Time
Stations
Topics
Mon 31.07.
now
all
all
until 17:00 17:00 18:00 19:00
Charmed - Zauberhafte Hexen
END
MENU
arte 15:57-16:59 Charmed - Zauberhafte Hexen
Das Erste 16:00-16:10 Tagesschau
ZDF 16:00-16:10 heute - in Europa
WDR Köln 16:00-16:15 WDR aktuell
Bayerisches... 16:00-16:05 Rundschau
hr-fernsehen 16:00-16:30 Schlemmerreise Spanien
MDR FERNS... 16:00-16:15 Hier ab vier
NDR FS HH 16:00-16:30 Tipps und Trends - Der Verbraucher...
SWR Fernse... 16:00-16:05 Baden-Württemberg aktuell
2 ZDF
EPG (Electronic Programme Guide) Mon 31.07./16.05
Change to programme list
Date
Time
Stations
Topics
Mon 31.07.
now
all
all
Tue 01.08. Wed 02.08. Thu 03.08.
F
Charmed - Zauberhafte Hexen
