- 38
Other settings
Parental lock
You can select and set various security options to prevent unauthorised
use of the TV set and to protect your children from unsuitable pro-
grammes.
Defining the access code ( PIN)
Call TV menu.
Select Settings,
go to the menu line below.
Select Parental lock,
go to the menu line below.
Define a four digit access code (PIN) the first time
you open it. The numbers appear in plain text. Note
the access code (PIN) well.
OK Confirm the access code (PIN).
The Parental lock menu is opened.
The four-digit access code (PIN) must be entered when
the parental lock is opened in future. It appears encrypted
(****) when entering for security reasons.
Code number
The code number cancels all entered PINs. It can be used for example if
you have forgotten your PIN. You will find a note about the code number
on page 64. Remove this from the manual and keep it in a safe place.
Explanations of setting possibilities in the Parental lock menu:
The TV set is locked immediately on exiting the menu.
Programmes of any kind can then only be watched after
entering the PIN.
The lock remains active until switching off in the menu.
The TV set is locked daily at the fixed time. Programmes
of any kind can then only be watched after entering
the PIN.
Some DVB stations also broadcast an age classification. If
the age set here is below the broadcast age limit, the pro-
gramme can only be watched after entering the PIN.
You can change your PIN at any time. Enter the new PIN
in place of the old one.
You can delete your entered PIN at any time.
Timer functions
This menu offers you convenient alarm services. Programmed alarms are
also active when the TV set has been switched off to standby.
If the TV set switches on from the standby mode by alarm, a screen
message appears. If this is not confirmed within 5 minutes with the OK
button, the TV switches back off automatically for safety reasons.
The TV set can also be switched off automatically at certain times. A screen
warning appears one minute before automatic switch off. The automatic
switch off can be interrupted by pressing any button.
Call Timer functions
Call TV menu.
Select Settings,
go to the menu line below.
Select Timer functions,
go to the menu line below.
Select the desired setting.
Explanations of setting possibilities in the Timer functions menu:
The set switches to the standby mode automatically at
the specified time.
If a time is specified which has already passed on the same
day, the set switches off at this time the next day.
The set regularly switches to the standby mode automa-
tically every day at the specified time.
The set alerts you once today at the specified time.
If a time was specified which has already passed on the
same day, the alarm is saved for the next day.
The set regularly alerts you from Monday to Friday at
the set time.
The set alerts you regularly every Saturday at the speci-
fied time.
The set alerts you regularly every Sunday at the specified
time.
Specify whether the TV set switches on in the event of an
alarm from the standby mode in TV or radio mode with
the respectively last active station.
Set the desired volume of the alarm tone. The alarm
tone is emitted as a continuous tone as a guide during
the setting.
Lock
immediately
Lock daily
Age-related
lock
Change
access code
Delete
access code
Switch off
today only
Switch off
daily
One-time
reminder
Wake up
Mon-Fri
Wake up Sat
Wake up
Sun
Wake up
with
Wake up
signal
volume
