![Dewalt D28886 [17/80] English](/views2/1205243/page17/bg11.png)
17
ENGLISH
DIE GRINDER D28885/D28886
Congratulations!
You have chosen a DEWALT tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical data
D28885 D28886
Voltage V 230 230
(U.K. & Ireland only) V 230/115
Power input W 500 710
No-load speed min
-1
27,000 7,000 - 27,000
Collet nut mm 6 6
Weight kg 1.4 1.8
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
The following symbols are used throughout this
manual:
Denotes risk of personal injury, loss of life
or damage to the tool in case of non-
observance of the instructions in this
manual.
Denotes risk of electric shock.
Fire hazard.
EC-Declaration of conformity
D28885/D28886
DEWALT declares that these power tools have been
designed in compliance with: 98/37/EEC,
89/336/EEC, 73/23/EEC, EN 50144, EN 55014-2,
EN 55014-1, EN 61000-3-2 & EN 61000-3-3.
For more information, please contact DEWALT at the
address below, or refer to the back of the manual.
Level of sound pressure according to 86/188/EEC &
98/37/EEC, measured according to EN 50144:
D28885 D28886
L
pA
(sound pressure) dB(A)* 78 78
L
WA
(acoustic power) dB(A) 91 91
* at the operator’s ear
Take appropriate measures for the
protection of hearing.
Weighted root mean square acceleration value
according to EN 50144:
D28885 D28886
5 m/s
2
5 m/s
2
Director Engineering and Product Development
Horst Großmann
DEWALT, Richard-Klinger-Straße 11
D-65510, Idstein, Germany
