Netgear DGN2200 [11/124] Router back panel

Internet Configuration

N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition

Router Back Panel

The back panel of the wireless modem router contains port connections.

Ethernet LAN ports

Power On/Off button

Power adapter input

USB mobile broadband

DSL
