Netgear DGN2200 [7/124] Internet configuration

1. Internet Configuration

This chapter describes how to configure your N300 Wireless ADSL2+ Modem Router

DGN2200M Mobile Edition Internet connection. For help with installation, see the N300 Wireless

ADSL2+ Modem Router DGN2200M Mobile Edition Installation Guide.

This chapter covers the following topics:

• Hardware Features

• System Setup

• Log In to Your Wireless-N Modem Router

• Use the Setup Wizard after Installation

• Manually Configure Your Internet Settings

For more information about the topics covered in this manual, visit the support website at

http://support.netgear.com.
