Netgear DGN2200 [51/124] Minimal software installation

Protecting Your Network

N300 Wireless ADSL2+ Modem Router DGN2200M Mobile Edition

Minimal Software Installation

Installation requires a one-time installation of a management utility program. Once Live

Parental Controls is set up, the software runs in the background and does not interfere with

normal Internet usage.
