Configuration Guide 256

Configuring Spanning Tree Configuration Example for MSTP

6) Click Save Config to save the settings.

5.4 Using the CLI



Configurations for Switch A

1) Enable the spanning tree function on port 1/0/1 and port 1/0/2, and specify the path cost of

port 1/0/1 in instance 1 as 400000.

Switch#congure

Switch(cong)#interface gigabitEthernet 1/0/1

Switch(cong-if)#spanning-tree

Switch(cong-if)#spanning-tree mst instance 1 cost 400000

Switch(cong-if)#exit

Switch(cong)#interface gigabitEthernet 1/0/2

Switch(cong-if)#spanning-tree

Switch(cong-if)#exit

2) Configure the region name as 1, the revision number as 100; map VLAN101-VLAN103 to

instance 1; map VLAN104-VLAN106 to instance 2:

Switch(cong)#spanning-tree mst conguration

Switch(cong-mst)#name 1

Switch(cong-mst)#revision 100

Switch(cong-mst)#instance 1 vlan 101-103

Switch(cong-mst)#instance 2 vlan 104-106

Switch(cong-mst)#exit

3) Configure the spanning tree mode as MSTP, then enable spanning tree function globally.

Switch(cong)#spanning-tree mode mstp

Switch(cong)#spanning-tree

Switch(cong)#end

Switch#copy running-cong startup-cong
