Tp-Link Archer C9 [118/119] Explanations of the symbols on the product label

114

Explanations of the symbols on the product label

Symbol Explanation

DC voltage

RECYCLING

This product bears the selective sorting symbol for Waste electrical and electronic

equipment (WEEE). This means that this product must be handled pursuant to

European directive 2012/19/EU in order to be recycled or dismantled to minimize

its impact on the environment.

User has the choice to give his product to a competent recycling organization or to

the retailer when he buys a new electrical or electronic equipment.
