Tp-Link Archer C9 [9/119] Panel layout

Chapter 1

Get to Know About Your Router

1. 3. Panel Layout

1. 3. 1. The Front Panel

The router’s LEDs (view from left to right) are located on the front. You can check the

router’s working status by following the LED Explanation table.

LED Explanation

Name Status Indication

(Power)

On System initialization completes.

Flashing

System initialization or firmware upgrade is in process. Do not

disconnect or power off the router.

Off Power is off.

(2.4GHz Wireless)

On The 2.4GHz wireless band is working properly.

Off The 2.4GHz wireless band is disabled.
