Tp-Link Archer C9 [12/119] 3 the side panel

Chapter 1

Get to Know About Your Router

1. 3. 3. The Side Panel

The following parts (View from top to bottom) are located on the side panel.

Item Description

WiFi Button

Press the WiFi button for about 2 seconds to turn on or off the wireless function

of your router.

USB 3.0 Port

For connecting to a 3.0 USB storage device or a 3.0 USB printer. It is also compatible

with USB 2.0 devices.
