Aten KL1516Ai [129/239] Ap gui interface

Chapter 9. Port Access

113

AP GUI Interface

The AP GUI Access Rights page is similar to the Browser GUI version (see

above), except that there is no checkmark icon in the Access column.

 Click the text in the Access column to toggle permission between Full

Access, View Only, and No Access.

Saving Changes

Click the Save button at the lower right corner of the page to save any changes

made on the Access page.
