Appendix
191
Specifications
Function KL1508Ai KL1516Ai
Computer
Connections
Direct 8 16
Max. 128 (via Daisy Chain) 256 (via Daisy Chain)
Console
Connections
Local
1
Remote
Port Selection OSD, Hotkeys, Pushbutton
Connectors Console
Ports
Keyboard 1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type-A Female (White)
Video 1 x HDB-15 Female (Blue)
Mouse 1 x 6-pin Mini-DIN Female (Green)
1 x USB Type-A Female (White)
KVM Ports 8 x RJ-45 Female 16 x RJ-45 Female
Daisy Chain 1 x DB-25 Male (Black)
Power 1 x 3-prong AC socket
F/W Upgrade 1 x RJ-11 Female (Black)
External Mouse 1 x USB Type A Female
LAN 1 x RJ-45 Female
PON 1 x RJ-45 Female
Switches Power 1 x Rocker
LCD Power 1 x Pushbutton
LCM Adjustment 4 x Pushbutton
Port Selection 8 x Pushbutton 16 x Pushbutton
FW Upgrade 1 x Slide
KVM Reset 1 x Semi-recessed Pushbutton
Station 2 x Pushbutton
