Aten KL1516Ai [61/239] Continued from previous page

Chapter 4. OSD Operation

(Continued from previous page.)

Setting Function

SET

CONSOLE

MODE

This setting selects which console(s) (internal/external) are enabled:

0 Both Consoles enabled

1 LCD Console only

2 External console only

Use the spacebar to cycle through the choices. The default is 0.

Changes will not be saved until you logout.
