Chapter 1. Introduction
7
Requirements
General
We recommend computers with at least a P 4 2GHz processor, and 1 GB
RAM.
Browsers must support TLS 1.2 encryption.
A network transfer speed of at least 512kbps is recommended.
For the Log Server, you must have the Microsoft Jet OLEDB 4.0 or higher
driver installed.
External Console
A VGA, SVGA, or Multisync monitor capable of the highest resolution
that you will be using on any computer in the installation.
A USB or PS/2 style mouse
A USB or PS/2 style keyboard
Computers
The following equipment must be installed on the computers that connect to the
KL1508Ai or KL1516Ai's KVM ports:
A VGA, SVGA or Multisync port
A Type A USB port and USB host controller (for USB KVM Adapter
Cable Connection, see below)
6-pin mini-DIN keyboard and mouse ports (for PS/2 KVM Adapter Cable
Connection, see below)
Note: The integrated LCD monitor’s maximum screen resolution is 1280
x 1024 @ 75 Hz. If you want to use a higher setting for the screen
resolutions of the attached computers, see Screen Resolutions
Higher than 1280 x 1024, page 206.
KVM Adapter Cables
Cat 5e/6 cable is required to connect the KL1508Ai / KL1516Ai to one of the
KVM adapter cables.
