ECS Elitegroup H81H3-TI2 (V1.0) [12/60] Chapter 2

Chapter 2

H81H3-TI2 USER MANUAL

This section explains how to set jumpers for correct configuration of the

motherboard.

2-3. Checking Jumper Settings

1. LCD_SEL: LCD panel select header (For All-In-One Specification)

1.When your panel connects to LVDS, please check LCD_SEL header setting

first.

2.Due to the differences of the panel parameters, please follow the above

illustration to place the jumper caps.

No. Components

1LCD_SEL

2LCD_PWR

3CLR_CMOS
