H81H3-TI2 USER MANUAL

Chapter 1

Table of Motherboard Components

LABEL COMPONENTS

1. CPU Socket

LGA1150 socket for Intel® 4

Generation Core

Family Processors

2. DMIC Digital microphone header (For All-In-One Specification)

3. SPKR Speaker header (For All-In-One Specification)

4. F_AUDIO Front panel audio header

5. CLR_CMOS Clear CMOS jumper

6. CASE Case open header

7. PCIE1~2

Mini PCI Express slots (mini PCIE1 (full-card) supports extension cards with SATA

signal, USB signal and PCIE signal, and mini PCIE2 (half-card) supports extension

cards with PCIE signal & USB signal.)

8. F_USB Front panel USB 2.0 header

9. SATA_PWR SATA power connector

10. USB_CR 5-pin USB 2.0 header supports card reader or other USB 2.0 device

11. USB_CAM 5-pin USB 2.0 header supports camera or other USB 2.0 device

12. USB_TP 5-pin USB 2.0 header (yellow) supports touch panel or other USB 2.0 device

13. SATA2 Serial ATA 3Gb/s connector

14. SATA1 Serial ATA 6Gb/s connector

15. SYS_FAN 4-pin system cooling fan connector with smart fan function

16. CPU_FAN 4-pin CPU cooling fan connector with smart fan function

17. LDC Debug card header

18. CIR Consumer infrared header

19. F_PANEL Front panel switch/LED header

20. MON_SW LVDS brightness switch header (For All-In-One Specification)

21. LCD_SEL LCD panel select jumper (For All-In-One Specification)

22. LVDS LVDS connector (For All-In-One Specification)

23. DISP_BRT LVDS brightness control header (For All-In-One Specification)

24. LCD_PWR LVDS select jumper (For All-In-One Specification)

25. SODIMM 204-pin DDR3 SDRAM SO-DIMM
