Chapter 3
H81H3-TI2 USER MANUAL
40
CIR Controller (Enabled)
This item allows you to enable or disable CIR controller.
Scroll to this item and press <Enter> and view the following screen:
CIR Controller Configuration
Enable or Disable CIR
Controller
CIR Controller Configuration
CIR Controller Enabled
Super IO Configuration
Use this item to show the information of Super IO configuration.
F71808A Super IO Chip (F71808A)
This item shows the information of the super IO chip.
Set Parameters of CIR
Controller (CIR)
Super IO Configuration
F71808A Super IO Chip F71808A
CIR Controller Configuration
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Press <Esc> to return to the Super IO Configuration page.
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset Boot Security Exit
Main Advanced Chipset Boot Security Exit
