Chapter 3
H81H3-TI2 USER MANUAL
36
Enabled for Windows XP
and Linux (OS optimized for
Hyper-Threading
Technology) and Disabled
for other OS (OS not
optimized for
Hyper-Threading
Technology). When
Disabled only one thread
per enabled core is
enabled.
Intel(R) Core(TM) i3-4330T CPU @ 3.00GHz
This is display-only field and displays the information of the CPU installed in your
computer.
EM64T (Supported)
This item shows the computer supports EM64T.
Processor Speed (3000MHz)
This item shows the current processor speed.
Processor Stepping (306c3)
This item shows the processor stepping version.
Microcode Revision (9)
This item shows the Microcode version.
Processor Cores (2)
This item shows the core number of the processor.
Intel HT Technology (Supported)
This item shows the computer supports Intel HT Technology or not.
CPU Configuration
The item in the menu shows the CPU configuration.
Enter/Dbl Click : Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
/Click: Select Item
: Select Screen
Intel VT-x Technology (Supported)
This item shows the computer supports Intel VT-x Technology or not.
Hyper-threading (Enabled)
This item only available when the chipset supports Hyper-threading and you are
using a Hyper-threading CPU.
CPU Configuration
Intel(R) Core (TM) i3-4330T CPU @ 3.00GHz
EM64T Supported
Processor Speed 3000 MHz
Processor Stepping 306c3
Microcode Revision 9
Processor Cores 2
Intel HT Technology Supported
Intel VT-x Technology Supported
Hyper-threading Enabled
Active Processor Cores All
Limit CPUID Maximum Disabled
Execute Disable Bit Enabled
Intel Virtualization Technology Enabled
LakeTiny Feature Enabled
CPU C3 Report Enabled
CPU C6 Report Disabled
CPU C7 Report CPU C7s
Package C State limit AUTO
Enhanced Halt (C1E) Enabled
