ECS Elitegroup A55F-M3 [26/72] Installing the motherboard

Installing the Motherboard

ATX12V: ATX 12V Power Connector

Pin Signal Name

4 +12V

3 +12V

2 Ground

1 Ground

SPK: Internal speaker

Pin Signal Name

1 VCC

2 Key

3 GND

4 Signal
