3
Expansion Options
• One PCI Express x16 slot for Graphics Interface
• One PCI Express x1 slot
• One 32-bit PCI v2.3 compliant slot
• Four 7-pin SATA connectors
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
• PS/2 keyboard and PS/2 mouse connectors
• Four USB 2.0 ports
• One D-sub (VGA) port
• One LAN port
• Audio jacks for microphone, line-in and 6-ch line-out
BIOS Firmware
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
The firmware can also be used to set parameters for different processor clock
speeds.
The motherboard uses AMI BIOS that enables users to configure many sys-
tem features including the following:
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50°C.
The motherboard comes with the following expansion options:
Introducing the Motherboard
Onboard LAN (Optional)
The onboard LAN provides the following features:
• Supports PCI Express
TM
1.1
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
• Supports PCI Express
TM
1.1
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
