ECS Elitegroup A55F-M3 [35/72] Using bios

Using BIOS

• CPU Tct1

• CPU FAN

• SYS FAN

• CPU Vcore

• DIMM Voltage

• SB Voltage

System Component Characteristics

These items display the monitoring of the overall inboard hardware health

events, such as System & CPU temperature, CPU & DIMM voltage, CPU &

system fan speed,... etc.

Press <Esc> to return to the Advanced Menu page.

Press <Esc> to return to the PC Health Status page.
