ECS Elitegroup A55F-M3 [48/72] Using bios

Using BIOS

This page enables you to set setup administrator password and user password.

Security Menu

Set Setup Administrator

Password

Administrator Password

Main Advanced Chipset M.I.B.III Boot Security Save & Exit

Administrator Password

Press <Enter> to setup administrator password.

Enter/Dbl Click : Select

+/- : Change Opt.





: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit
