43
Using BIOS
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.13.1216. Copyright (C) 2011 American Megatrends, Inc.
Select the keyboard NumLock
state
Boot Option #1 [SATA: WDC WD5000AA...]
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
Network Device Priorities
This item enables you to specify the sequence of loading the operating system from
the installing network devices.
UEFI Boot Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing UEFI Boot drives.
USB KEY Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB KEY drives.
Enter/Dbl Click : Select
+/- : Change Opt.
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
