Belkin F5L049EA [19/59] Picture sharing
![Belkin F5L049EA [19/59] Picture sharing](/views2/1227327/page19/bg13.png)
17
Home Base
SECTIONSTable of Contents 1 2 3 4 5 6 8 9 1510 11 12 13 147
PICTURE SHARING
Flickr Account Selection
A Flickr account is selected here. Next to “User Name”, the user names
stored in Home Base are displayed in a combo box.
If a new user name is entered, Flickr tool authorization is necessary. In
this case, clicking “Next” will bring up the following message.
