5
Home Base
SECTIONSTable of Contents 1 2 4 5 6 7 8 9 1510 11 12 13 14
WIRELESS SETUP
3
There are three ways to attach your Home Base to your wireless
network:
• WiredSetupofWirelessMode
• WPSPushButtonConfiguration
• WPSPINConfiguration
Wired Setup of Wireless Mode
Note: If Home Base is powered on while plugged into a router, it will
operate as a wired device. To enable Wireless mode, follow instructions
below.
The setup software will help you make Home Base operate as a member
of your wireless network.
1. Start by connecting your Home Base to your router. (You’ll unplug
it later.)
2. Connect the AC adapter.
3. Run the setup software and follow the software’s instructions to set
up the Home Base.
4. When offered wireless setup, select a wireless network.
5. The setup software will tell Home Base what network you chose.
Follow the software’s instructions to unplug your Home Base from
the router and turn it off and on.
6. Your Home Base will then operate as a member of your wireless
network.
