Gigabyte G1.Sniper Z6 [19/80] 6 back panel connectors

- 19 -

1-6 Back Panel Connectors

(Note) TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• Whenremovingthecable,pullitstraightoutfromtheconnector.Donotrockitsidetosidetoprevent

an electrical short inside the cable connector.

This connector provides digital audio out to an external audio system that supports digital coaxial audio.

Before using this feature, ensure that your audio system provides a coaxial digital audio in connector.

D-Sub Port

TheD-Subportsupportsa15-pinD-Subconnectorandsupportsamaximumresolutionof1920x1200@60Hz

(theactualresolutionssupporteddependonthemonitorbeingused).Connectamonitorthatsupports

D-Sub connection to this port.

DVI-D Port

(Note)

TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof1920x1200@60Hz

(theactualresolutionssupporteddependonthemonitorbeingused).Connectamonitorthatsupports

UsethisportforUSBdevicessuchasaUSBkeyboard/mouse,USBprinter,USBashdriveandetc.

HDMI Port

The HDMI port is HDCP compliant and supports Dolby True HD and DTS HD

MasterAudio formats. It also supports upto 192KHz/24bit 8-channel LPCM

audio output. You can use this port to connect your HDMI-supported monitor. The maximum supported

resolutionis4096x2160@24Hzor2560x1600@60Hz,buttheactualresolutionssupportedaredependent

on the monitor being used.

Triple-DisplayCongurationsfortheOnboardGraphics:

 Triple-displaycongurationsaresupportedafteryouinstallmotherboarddriversinOS.Onlydual-display
